RA-885
The RA-885 features a straight forward design with a 304SS mesh-chain delivery system, rear-mounted 72-ft. and 90-ft booms, application rates of up to 1,200 lbs. per acre, and an industry-leading 350 CU FT capacity. Capable of delivering up to three products, bin dividers can adjust to a 50/50 or 60/40 split between the two main bins. A micro hopper can stand alone or be used to supplement the second bin.
Air Spreader Specifications
Applicator Specifications |
RA-885 |
|---|---|
| Single Product Capacity | 350 CU FT |
| Multi Product capacity | Bin 1: Adjustable 175 CU FT or 209 CU FT Bin 2: Adjustable 95 CU FT., 140 CU FT, or 174 CU FT Micro Bin: 45 CU FT |
| Box Material | 409SS Painted Red |
| Booms | 72' 304SS with 32 outlets or 60' 304SS on 30" on-center outlets or 90' 304SS with 37 outlets |
| Metering System | Bins 1 & 2: LH & RH independently driven 16" 304SS mesh chains. Micro Bin: LH/RH roller meters, clutched controlled on/off. |
| Fan | Single 22" Fan |
| Features | Viper 4+, 7' break-away tips, VRA capable for up to 3 products |
